Feed TSCY Grain Pre Cleaner
TSCY series cylinder Drum sieve pre cleaner is widely used the primary cleaning of all cereals, corn, canola, peas and similar products before drying or storage.
Drum Pre cleaner has capacities ranging from 10 to 300t/h. All these pre cleaners have effective suction systems for separation of light products such as chaff, straw, light grain, pods, etc and wheat straw, rope head, bean straw, bean skin, small wooden block, bricks, stones, mud, etc.
It is the ideal pre-cleaning equipment for flour mills, storage warehouses, rice mills, oil mills, sprinkling mills, starch mills, monosodium glutamate plants, feed mills, chemical plants and other solid particle material plants that need to be cleaned and classified.
Cylinder Initial Cleaning Sieve
Cylinder Initial Cleaning Sieve
Cylinder Initial Cleaning Sieve
Feed TSCY Grain Pre Cleaner
Double-Cylinder Initial Cleaning Screen
Cylinder Initial Cleaning Sieve Parameter
Model TSCY85/100 TSCY100/125 TSCY125/150 TSCY125/250 TSCY125/320
Capacity(T/H) Wheat,corn,Soybean 20-100 40-150 50-200 80-260 100-300
Rice 10-30 30-90 40-100 60-120 80-160
Rotating speed(r/min) 17 17 15 15 15
Power(kw) 1.5 2.2 2.2-3 2.2-4 2.2-5.5
Suction volume(m³/h) 980 1380 1820 2250 2680
Sieve size(mm) 850*1050 1000*1250 1250*1500 1250*2500 1250*3200

Double-cylinder initial cleaning screen
Model TCQYS85/190 TCQYS100/220 TCQYS100/320 TCQYS100/420 TCQYS125/320 TCQYS125/420
Capacity(T/H) Inner mesh diameter(mm) 22 60 80 110 140 140 170
20 50 70 100 120 120 150
18 40 60 90 110 100 120
16 30 50 70 100 90 110
Out mesh diameter(mm):1.8-3.2

Product Feature
1) High capacity for cleaning large impurity (10-300T/h).
2) Heavy duty roller support system for high throughput operation.
3) Extended drum length ensures cleaning efficiency.
4) Reliable roller chain drive mechanism for stable processing.
5) Dust cover structure ready for hooking up into central cleaning system.
6)Option of portable structure
7) Laser cutting applies to sheet metal components for quality and accuracy.
8) Carbon dioxide gas shielded welding workmanship.
9) CNC machining centers ensure precise fabrication
10) Powder coated parts and components for best quality and duration.
